Computer 24" Lcd Led Monitor Screen
Computer Monitor
Enquiry
Overview
Tech Specs
Downloads
Overview
Tech Specs
BHB LED MONITOR
Model
MP24028
Panel size
23.8/23.6
Panel type
TFT-LCD
Panel manufacturer
CSOT/BOE/HKC/PANDA/AUO (panel different the specifications maybe different)
Panel technology
VA
Backlight type
ELED
View angle
178° (H) / 178° (V)
Max. Resolution
1920×1080
Aspect Ratio
（
H:V
）
16: 9
Refresh rate(Hz)
75hz
Brightness
230 cd/
㎡
( /-20%)
Surface treatment
Matte (Haze 25%)
Contrast Ratio
3000:1 (Typ.)
Point spacing
0.0915×0.2745 mm
Pixel pitch
0.2745×0.2745 mm
Color quantity
16.7M
（
8-bit
）
Color gamut
99% sRGB
Display mode
Normally Black
Pixel arrangement
RGB Vertical Stripe
Response time
5ms
（
OD
）
Dynamic Contrast Ratio
（
DCR
）
1000000: 1
Reduce BLU-RAY Mode
YES
Tempered glass attachable structure
NO
Other Features
Free-Sync
（
G-Sync
）
YES
Game plus
YES
curvature
1500R
HDR function
YES
VESA
75 * 75mm
Input/
Output interface
HDMI input
yes
DVI input
/
VGA input
YES
Display port input
/
Type-C input
/
SPDIF OUT
/
Headphone Output
yes
USB
YES
Built -in speaker
Optional
Pow
er
Power supply mode
External power supply
AC input
100-240V,50/60Hz,1.0A
DC input
12V-3A
Power Consumption
＜
36W
Stand by Mode
0.16W
Off Mode
0.16W
Acce
ssory
HDMI signal line
YES
DVI signal line
/
VGA signal line
/
DP signal line
/
Type-C signal line
/
Power line
YES
Audio line
/
Manual
YES
Qualified Certificate
YES
power adapter
YES
Packi
ng
Carton dimension (L*W*H)
594*104*386MM
Product size
540x420mm(including base)
Gross weight
3.6KG
Net weight
2.35kg
Loading quantity
20GP--900PCS
40HQ--2000PCS
