CAMERA
|
|
IMAGEING DEVICE
|
1/3.2" CMOS module
|
|
MAIN CAMERA
|
8,000,000 Pixels ( 3264x2448)
|
|
FRAME RATE
|
15mfps @3264*2448 30 mfps @1080P
|
|
ZOOM
|
10X ( 10 digital)
|
|
SPECIFICATION
|
|
Case
|
Metal case
|
|
Tray
|
plastic
|
|
PORTS
|
USB2.0
|
|
scan speed
|
0.01 second
|
|
HDMI OUT
|
NO
|
|
OUTPUT
|
DRIVER-FREE USB2.0
|
|
AV OUT
|
NO
|
|
VIDEO FREEZE
|
Yes
|
|
EFFECTIVE AREA
|
A4
|
|
LIGHT
|
EMBEDDED LED
|
|
SHUTTER SPEED
|
1 SECOND
|
|
FREEZE
|
YES
|
|
ZOOMING
|
MOUSE WHEEL ZOOMING
|
|
SOFTWARE
|
|
IMAGE VIEWING
|
COLOR/BW, MIRROR, 90 DEGREE ROTATION, NEGATIVE(OPTIONAL)
|
|
IMAGE PROCESSING
|
90 DEGREE ROTATION, MARK, CUT, PDF TRANSFERING
|
|
PHOTO SHOOTING
|
YES(RESOLUTION ADJUSTABLE, 9-IMAGE PREVIEWING)
|
|
VIDEO RECORDING
|
YES (WMV,AVI)
|
|
CONTINUOUS FRAME
|
YES(FRAME ADJUSTABLE)
|
|
AUDIO/VIDEO RECORDING
|
OPTIONAL
|
|
PDF FORMAT
|
YES
|
|
OCR function
|
supported multi-language OCR
|
|
POWER
|
USB POWER
|
|
AUXILIARY LIGHT
|
LED LIGHT
|
|
OTHERS
|
|
SOFTWARE FUNCTIONS
|
Document camera, whiteboard mark, PDF transfering
|
|
POWER
|
DC 5V
|
|
W xD xH
|
Set up：385*330*370mm， Folded：330*350*70mm
|
|
NET WEIGHT
|
4.5KGS
|
|
Gross WEIGHT
|
6KGS
|
|
CARTON SIZE
|
110*330*170mm
|
|
Warranty time
|
one year
|
