BHB-W63

Main Features

● 30x Optical + 8x Digital Zoom

High quality super telephoto lens, 30x optical zoom, and 8x digital zoom.

● H.265 Support

H.265 support, enabling full HD 1080p video stream by ultra-low bandwidth.

● 1080P Full HD

Apply Panasonic's 1/2.7 inch, 2.07 million effective pixels high quality HD CMOS sensor, can reach maximum 1920 x 1080

high resolution and achieve quality image.

● Ultra-high Frame Rate

The output frame rate up to 60fps in 1080P.

● AAC Audio Encoding

Support AAC audio encoding, better sound quality and smaller bandwidth.

● Local Storage

Support local storage module, directly recording to local USB flash disk without NVR.

● Low-light

High SNR of CMOS sensor combined with 2D and 3D noise reduction algorithm, effectively reduce the noise, even

under low illumination conditions, picture can still keep clean and clear.

● Remote Control

Using RS232/485 interface, all the parameters of the camera can be remote controlled by the high-speed communications.

Model

BHB-W63

Name

HD Video Conference Camera

Camera

Video System

HD: 1080p/60, 1080p/50, 1080i/60, 1080i/50, 1080p/30, 1080p/25, 720p/60, 720p/50, 720p/30, 720p/25,

 640x480p/240

SD: 480i, 576i

Sensor

1/2.7'', CMOS, Effective Pixel: 2.07M

Scanning Mode

Progressive

Lens

30x, f4.42mm ~ 132.6mm, F1.8 ~ F2.8

Digital Zoom

8x

Minimal Illumination

0.5 Lux @ (F1.8, AGC ON)

Shutter

1/30s ~ 1/10000s

White Balance

Auto, 3000K/Indoor, 4000K, 5000K/Outdoor, 6500K_1, 6500K_2, 6500K_3, One Push,

Manual

Backlight Compensation

Support

Digital Noise Reduction

2D&3D Digital Noise Reduction

Video S/N

≥55dB

Horizontal Angle of View

60.7° ~ 2.28°
