Model Number

BHB M04

Camera Parameters

Sensor

high quality HD CMOS sensor

Effective Pixels

16：9 ,2.07 megapixels

Video Format

1920x1080@30fps/25fps;1600x896@30fps/25fps;1280x720@30fps/25fps; 1024x576@30fps/25fps;960x540@30fps/25fps;800x600@30fps/25fps; 800x448@30fps/25fps;720x576@30fps/25fps;720x480@30fps/25fps;640x480@30fps/25fps;640x360@30fps/25fps;480x270@30fps/25fps;320x240@30fps/25fps; 352x288@30fps/25fps; 320x240@30fps/25fps;320x180@30fps/25fps

View Angle

92°（D）/85°（H）/ 52°（V）

Focal Length

3.24mm

Minimum illumination

0.5Lux(F1.8, AGC ON)

Focus

Manual

Aperture

Fixed

Backlight Contrast

On/OFF

Exposure

Exposure parameter could be adjusted; support auto exposure

Video Adjustment

Brightness, Color, Saturation, Contrast, White balance mode, Gain, Anti-flicker, Low brightness compensation etc

SNR

>50dB

Input/Output Interface

Video Interfaces

USB2.0 (power supply, upgrading available)

Video Compression Format

MJPEG,YUY2, H.264, NV12

Audio Input Interface

Built in omnidirectional high sensitive digital pickup

Other Parameter

Input Voltage

5V

Input Current

500mA(Max.）

Power consumption

2.5W(Max.)

Store Temperature

-10℃～+60℃

Store Humidity

20%～95%

Working Temperature

-10℃～+50℃

Working Humidity

20%～80%

Dimension（WXHXD）

102mm*47mm*30mm

Weight (appx.)

0.15kg

Application

Indoor

Accessory

User Manual
