PERFORMANCE FEATURES
1. Built-in amplifier, super bass + satellite speaker circuit design, exquisite sound.
2. Long-stroke super woofer unit, powerful bass.
3. Broad dynamic and low distortion.
4. Stable transformer supply power and low wastage, provide efficient transferring and ensure powerful bass.
5. Connect directly with PC, VCD, CD, DVD, TV, etc, for all audio needs.
6. Anti-magnet design ensures no disturbance to the PC or TV even when placed next to it.
7. Conveniently located, volume control for front, woofer and tweeter.
8. Modern style, black shining front panel, keep your desktop looking sharp
OPERATION
1. Please connect the audio cable from satellite speaker to the main box terminal (OUTPUT) according on the polarity, and make sure that you press the terminal connection tightly.
2. Connect the signal cable (INPUT) to the main box terminal input. (according to the audio input cap)
3. To start the unit, first adjust the knob on the front panel for VOLUME, BASS to the lowest. Then, turn on the power which will be indicated by the light on the unit.
4. Play the music as you like, and adjust the volume, bass to your preferred sound quality.
CONNECT USING BLUETOOTH TECHNOLOGY
1. Turn ON the unit
2. Activate the Bluetooth function on your Bluetooth Device (Mobil
Phone or Tablet).
3. Once you have activated Bluetooth on your device, select the
" S-2010 "from the list of available Bluetooth devices.
4. If required, enter the password"0000"to confirm pairing.
SPECIFICATIONS
P.M.P.O.: 17W
Input impedance: 10K Ohm
Input port: stereo 3.5mm line in
Control: volume / bass/USB/SD
Woofer unit impedance: 6 Ohm
Speaker unit: Woofer: 4"6 Ohm 6W * 1 (Magnetic shield)
Satellite: 3"4 Ohm 3W * 2(Magnetic shield)
Power input: AC 220-240V 50/60Hz
Dimensions:
*Subwoofer: 133 (W)*195(H)*245 (D)mm
*Satellite: 93(W)*133 (H)*96 (D)mm
